600W LED Explosion Proof Flood Light 30° Boom Pole Long-Range Site Perimeter Grey ATEX IIB T6 IP65 RFEPL8280 Lighting
Detalhes do produto:
| Lugar de origem: | Cantão, China |
| Marca: | ECER |
| Certificação: | ATEX Ex db mb IIB T6, CE, ROHS, CCC |
| Número do modelo: | RFEPL8280-600W-BM30 |
Condições de Pagamento e Envio:
| Quantidade de ordem mínima: | 10 peças |
|---|---|
| Preço: | Negociável |
| Detalhes da embalagem: | Caixa de embalagem + bolha ou sob medida |
| Tempo de entrega: | 10 a 15 dias ou confirmação |
| Termos de pagamento: | T/T, União Ocidental |
| Habilidade da fonte: | 5000 unidades/mês |
|
Informação detalhada |
|||
| Poder: | 600W | Eficiência luminosa: | 100-120LM/W. |
|---|---|---|---|
| Chip conduzido: | LUMILEDS SMD (LM-80) | Ângulo de feixe: | 30° |
| Temperatura de cor: | 5000K | Classificação IP: | IP65 |
| Marca à prova de explosão: | Ex db mb IIB T6 - IP65 - WF2 | proteção contra raios: | 6KV |
| Material: | Alumínio ADC12 + Vidro Temperado | Terminar: | Cinza |
| Certificação: | ATEX, CE, ROHS, CCC | Vida: | 50.000 horas |
| Temperatura operacional: | -40°C a +60°C | ||
| Destacar: | 600W explosion proof LED flood light,ATEX IIB T6 explosion proof lighting,long-range explosion proof perimeter light |
||
Descrição de produto
600W LED Explosion Proof Flood Light - 30° Boom Pole Long-Range Site Perimeter
The RFEPL8280-600W-BM30 is a 600W LED explosion proof flood light from the RFEPL8280 series, delivering 72000lm luminous flux with 120lm/W efficiency. ATEX Ex db mb IIB T6 certified with IP65 WF2 protection, this Grey finish floodlight features LUMILEDS SMD chip technology (LM-80 tested), 6KV lightning protection, and all-stainless-steel hardware passing 500-hour salt spray testing.
Key Features
- LUMILEDS SMD Technology - LM-80 tested premium LED chips delivering 120lm/W with CRI ≥80 and 50,000-hour L70 lifespan
- ATEX Ex db mb IIB T6 Certified - Zone 1/Zone 2 gas and Zone 21/Zone 22 dust hazardous atmospheres, temperature classes T1-T6
- 30° Beam Configuration - 30° Boom Mount Long-Range High Mast for precise light distribution
- Grey Paint Finish - Durable powder coat finish with 500-hour salt spray certification on all stainless steel hardware
- Die-Cast Fin Heat Dissipation - Advanced aluminum substrate thermal management for reliable 600W continuous operation
- 6KV Lightning Protection - Built-in surge suppression for exposed outdoor industrial installations
- 180° Adjustable Bracket - Flexible angle adjustment with six mounting configurations available
- IP65 Waterproof WF2 - Sealed against dust and water jets with corrosion-resistant design
- Universal AC 100-277V - Power factor ≥0.95, compatible with global electrical systems
- CE, ROHS, CCC Certified - Full international compliance for global deployment
Applications
Boom/pole-mounted long-distance illumination for access roads and site perimeters:
- Oil extraction, refining and petrochemical processing
- Offshore platforms, FPSOs and drilling rigs
- Chemical storage, mixing and manufacturing facilities
- Electric power generation and distribution stations
- Military and defense hazardous installations
Technical Specifications
| Model Number | RFEPL8280-600W-BM30 |
| Item No. | RFEPL8280 |
| Power | 600W |
| Light Efficiency | 100-120lm/W |
| LED Chip | LUMILEDS SMD (LM-80) |
| Beam Angle | 30° |
| CRI | ≥80 |
| Explosion-Proof Mark | Ex db mb IIB T6 - IP65 - WF2 |
| Lightning Protection | 6KV |
| Material | Aluminum ADC12 + Tempered Glass |
| Finish | Grey |
| Mounting | Ceiling / Boom / Bracket / Wall / Flange / Guardrail |
| Certification | ATEX, CE, ROHS, CCC |
| Lifetime | 50,000 Hours |
| Operating Temperature | -40°C to +60°C |
The RFEPL8280 series delivers industrial-grade hazardous area illumination with LUMILEDS LED efficiency and ATEX-certified safety. Every unit is factory-tested for explosion-proof integrity and photometric performance.
For bulk pricing, OEM customization, or technical consultation, please contact our sales team.
